SD-BD-04-01/Rev.10/29-03-67

             Space heater is an economical and reliable source of heat, widely used in the control panel, switchgear cubicle, main distribution board, control boxes etc. When it is in use, normally it should be combined with other products such as electric fan, thermostat or hygrostat.

             Heat element is a mica strip heater and the flat resistance ribbon generates heat over a broad area. Installation of the space heater should be at the bottom part of the cubicle or the lowest part of the control panel to get the best result of the heater.

             The complete set of space heater is rugged and modern design to fulfill the function of heating. The body of the heater is made of zinc-coated steel and painted with epoxy black color.
